Electric Pallet Jack 3300-4400 lb Capacity with 48"L x 27"W Forks Gel Battery Powered

$2,600.00 $2,259.00 Save $341.00
Model: R-1030
Capacity: 4400 lbs

Upgrade Notice: Add just $10 to move up to the 3900 lbs enhanced model.

If you prefer the upgraded version, simply select the 3900 lbs option on the product page when placing your order.

In stock

⛟ Shipping: Usually ships within 2 business days.

Shipping costs are calculated at checkout.

Capacity: 4400 lbs

Product details

The TORY CARRIER Flagship Electric Pallet Jack is engineered for customers who require higher durability, stronger performance, and longer service life in demanding material handling environments. Compared with standard models, this upgraded series features reinforced structural components, a brushless drive motor, and multiple battery configurations to deliver reliable performance for high-frequency warehouse operations.

Designed for warehouses, distribution centers, retail facilities, manufacturing plants, and container loading applications, this electric pallet jack combines compact maneuverability with heavy-duty capability. The improved drive system, enhanced stability features, and service-friendly design help operators move loads efficiently while reducing downtime.

Available Models
  • 3,300 lb Capacity: Equipped with a 24V / 65Ah GEL battery and 24V / 8A external charger for reliable daily handling operations.
  • 3,900 lb Capacity: Equipped with a 24V / 65Ah GEL battery and 24V / 5A built-in charger, balancing performance and convenience.
  • 4,400 lb Capacity: Equipped with a high-capacity 24V / 105Ah GEL battery and 24V / 10A built-in charger for extended operating time.
Key Features
  • High-Performance Brushless Drive Motor: The maintenance-friendly brushless motor provides efficient power delivery, smoother operation, and improved long-term reliability.
  • Extended Battery Options: Multiple battery configurations allow users to select the right balance between operating time, load requirements, and application needs.
  • Reinforced Structural Design: Upgraded chassis components and strengthened structural parts improve durability and stability during frequent material handling operations.
  • Floating Balance Wheel System: The floating support wheel design improves load distribution, reduces side movement, and enhances travel stability.
  • Reinforced Swingarm Mechanism: The improved swingarm structure helps reduce wear, maintain fork alignment, and improve long-term durability.
  • Protected Horizontal Drive Motor: The horizontal drive motor layout helps protect critical components from dust, water, and oil exposure during daily operation.
  • Ergonomic Multi-Function Handle: Integrated controls provide convenient operation of driving, lifting, lowering, horn, and emergency stop functions.
  • Turtle Speed Mode: Low-speed control mode allows precise positioning when operating in narrow aisles, containers, or crowded work areas.
  • Lift Limit Protection: The height limit switch helps prevent excessive lifting and provides additional protection for the hydraulic system.
  • Flexible Charging Solutions: Available built-in and external charger options provide convenient charging solutions for different operating environments.
  • Compact Space-Saving Design: The compact footprint makes it suitable for trailers, containers, warehouses, and other areas with limited operating space.
  • Battery Care Reminder: For extended storage periods, recharge the battery at least once a month to help maintain battery performance and service life.
Specification T-1029 T-1028 R-1030
Color Orange Orange Red
Load Capacity 3,300 lb 3,900 lb 4,400 lb
Load Center Distance 23.6 in. 23.6 in. 23.6 in.
Overall Dimensions (L × W × H) 70.1 × 27 × 50.2 in. 70.1 × 27 × 50.2 in. 70.1 × 27 × 50.2 in.
Minimum Fork Height 3.0 in. 3.0 in. 3.0 in.
Maximum Fork Height 7.3 in. 7.3 in. 7.3 in.
Fork Dimensions (W × L × T) 27 × 48 × 2.1 in. 27 × 48 × 2.1 in. 27 × 48 × 2.1 in.
Inside Fork Width 14.4 in. 14.4 in. 14.4 in.
Minimum Aisle Width 93.1 in. 93.1 in. 90.9 in.
Turning Radius 60.0 in. 60.0 in. 59.5 in.
Travel Speed (Loaded / Unloaded) 2.67 / 2.98 mph 2.70 / 3.00 mph 2.70 / 3.00 mph
Lifting Speed (Loaded / Unloaded) 1.0 / 1.2 in./s 1.0 / 1.2 in./s 1.0 / 1.2 in./s
Lowering Speed (Loaded / Unloaded) 1.4 / 1.0 in./s 1.4 / 1.0 in./s 1.4 / 1.0 in./s
Gradeability (Loaded / Unloaded) 5% / 20% 5% / 20% 5% / 20%
Battery Type GEL Battery GEL Battery GEL Battery
Battery Voltage / Capacity 24V / 65Ah 24V / 65Ah 24V / 105Ah
Charger 24V / 8A External Charger 24V / 5A Built-In Charger 24V / 10A Built-In Charger
Wheel Size Drive Wheel: 7.7 × 2.8 in.
Load Wheel: 2.9 × 3.7 in.
Balance Wheel: 1.7 × 0.7 in.		 Drive Wheel: 7.7 × 2.8 in.
Load Wheel: 2.9 × 3.7 in.
Balance Wheel: 1.7 × 0.7 in.		 Drive Wheel: 7.7 × 2.8 in.
Load Wheel: 2.9 × 3.7 in.
Balance Wheel: 1.7 × 0.7 in.
Ground Clearance 0.9 in. 0.9 in. 0.9 in.
Service Weight 487 lb 487 lb 530 lb
Warranty
Warranty Coverage 1-Year Limited Warranty
User Documentation

 Download the Tory Carrier Electric Pallet Truck Operation Manual (1029 / 1028 / 1030 Series)

👉Installation and Operation Video

Certifications & Compliance

Built to Meet Key Safety & Compliance Standards

Tory Carrier equipment is designed for dependable material handling performance, with selected models meeting applicable CE, EMC, and UKCA compliance requirements. Please verify certification availability for the specific model before purchase.

CE

CE Marked

Indicates conformity with applicable European safety, health, and environmental protection requirements.

EMC

EMC Compliant

Designed to meet electromagnetic compatibility requirements for stable and safe electrical operation.

UKCA

UKCA Marked

Indicates conformity with applicable UK product compliance requirements for selected equipment models.

Smart Dashboard Display

Displays battery level and fault codes clearly, with integrated key switch for easy machine control.

Protective Drive Wheel Cover

Protective wheel guard helps prevent foot injuries while moving through tight working areas.

Emergency Stop Button

Quick-response emergency stop enhances operator safety during operation.

Upper horizontal drive motor

1) Make replacing the driving wheel easier

2) Effectively prevent water, dust, and oil from sticking to the motor, to improve the working condition of the motor

Multi-function Control Handle

Incorporates butterfly-style thumb controls, emergency reversebutton, horn button and key switch for ease of use.

Durable Polyurethane Balance Wheel

Wear-resistant PU wheel provides smooth rolling, enhanced stability, and long-lasting performance for daily material handling tasks.

Electric Pallet Jack FAQ

What applications is this electric pallet jack suitable for?

This electric pallet jack is designed for warehouses, distribution centers, manufacturing facilities, retail backrooms, and loading docks where frequent pallet transportation is required.
What is the maximum load capacity?

This model can handle loads up to 3300/3900/4400 lbs. Do not exceed the rated capacity to ensure safe operation and extend equipment life.
How long can the battery operate on a full charge?

Battery runtime depends on load weight, operating frequency, and working conditions. Under normal warehouse operations, it provides reliable performance for daily material handling tasks.
How long does it take to charge the battery?

Charging time depends on the battery capacity and charger specifications. Please refer to the included user manual for detailed charging instructions.
Is this electric pallet jack easy to operate?

Yes. The ergonomic control handle allows operators to easily control lifting, lowering, forward, and reverse functions with minimal training.
What is included with the pallet jack?

Every order includes:
✅ Electric Pallet Jack (Main Unit)
✅ Ergonomic Handle
✅ User Manual
✅ Battery Charger

All items are securely packaged to ensure safe delivery.
Do I need to assemble the product?

Most of our products require minimal assembly before use. Assembly instructions are included with the product, and many models also have step-by-step installation videos available. If you need any assistance, our support team is happy to help.
Where does this product ship from?

Orders ship from our U.S. warehouses to provide fast delivery across the United States.
