Product details
Features
- Red dot and IF design award winner
- Fixed forks suits for EU-type pallet
- In-build charger, Use GEL battery-free to maintain
- Both sides of the button for lifting and lowering operation
- Small turning radius which is widely used in small warehouses and supermarkets
- Suit for low-level stacking and short-distance transportation.
- The turning radius and aisle width are very small, which is similar to a manual stacker.
Specification
| Load Capacity | 3300 LBS | 3300 LBS |
| Load Center Distance | 23.6 inch | 23.6 inch |
| Height, Mast Lowered | 72.4 inch | 82.2 inch |
| Lifting Height | 98 inch | 118 inch |
| Fork Dimensions | 45*6.7*2.3 inch | 45*6.7*2.3 inch |
| Lifting Speed(Laden/Unladen) | 4.3/5.5 inch/s | 4.3/5.5 inch/s |
| Travel Speed (Laden/Unladen) | 2.8/3.1 mph | 2.8/3.1 mph |
| Gradeability | 6%/15% | 6%/15% |
| Turning Radius | 53.7 inch | 53.7 inch |
| Battery Type | GEL | GEL |
| Battery Capacity | 24/125 V/Ah | 24/125 V/Ah |
| Service Weight | 1609 LBS | 1654 LBS |
