Product details
Key Features
-
Compact Design: Slim 29.5" width with a low stand height for easy maneuverability in tight spaces.
-
Safety-First Lifting: Automatic deceleration of lifting speed to ensure safe operation.
-
Intuitive Fingertip Control: Smooth steering and precise handling, even in narrow aisles.
-
Smart Control Handle: Integrated hand sensor activates travel, lift, and lower functions effortlessly.
-
Tow Capability: Equipped with a tractor tow device to pull trailers when needed.
-
Dual Foot Sensors: Detect proper foot placement on the platform for operator safety.
-
Adjustable Load Tray: 10.2" adjustable height for optimal working position (Load tray capacity: 200 lbs; Dock capacity: 330 lbs).
-
On-Board Charger: Convenient charging anytime, anywhere for uninterrupted operation.
Specs
| Load Capacity | 330 LBS |
| Operation Type | stand driving |
| Height, Mast Lowered | 49.5 inch |
| Max lifting Height | 118 inch |
| Lifting Speed(Laden/Unladen) | 5.5/5.5 inch/s |
| Travel Speed (Laden/Unladen) | 2.8/2.8 miles/h |
| Wheel Diameter | 7.1 inch |
| Turning Radius | 51.2 inch |
| Battery Type | GEL |
| Battery Capacity | 24/105 V/Ah |
| Service Weight | 1650 LBS |
